SPECFICATIONS
 Boost Clock: 2740 MHz
 Xe-Core: 20
 Ray Tracing Units: 20
 Intel® XMX Engines: 160
 GPU Peak Tops (Int8): 233
 Memory Size: 12GB GDDR6
 Graphics Memory Interface: 192-bit
 Graphics Memory Bandwidth: 456 GB/s
 Max Res.: Up to 8K at 120Hz HDR with DSC
 PCI Express Configurations: PCI Express 4.0 x8
 TBP: 200 Watt
 Lighting: Blue Breathing Light
 EAN: 4711342290771
KEY FEATURES
 TORN Cooling 2.0
 Metal Backplate, Pre-Installed
 Ray Tracing
 Variable Rate Shading (VSR)
 DirectX 12 Ultimate
 Vulkan 1.3
 OpenGL 4.6
 OpenCL 3.0
 Adaptive Sync
 AV1 Encode / Decode
 VP9 Bitstream & Decoding
 Intel Deep Link Hyper Compute
 Intel Deep Link Hyper Encode
 Intel Deep Link Stream Assist.
RESOLUTION & REFRESH
 HDMI 2.1 (Max): 7680 x 4320 @120Hz
 3x DisplayPort 2.1 (Max): 7680 x 4320@60Hz
REQUIREMENTS
10th Gen Intel® Core™ / AMD Ryzen™ 3000 Series
Processors or newer with compatible motherboards
supporting Resizable BAR / Smart Access Memory
 PCI-Express® compliant MB with one x16 PCIe slot
 600W or greater PSU with 1x 8-pin PCIe power connector
 8GB of system memory minimum, 16GB recommended
 Windows® 11 64-bit or Windows® 10 64-bit
DIMENSIONS
 Dimension: 315 x 117 x 44mm
 Weight: 954 g
 Width: 2.2-Slot
